All-new extreme data performance controller delivers up to 3,480MB/sec sequential read, and up to 3,000MB/s sequential write, for blazing fast read, write and response times.

HIGH-SPEED NVME PCIE GEN3 x4 M.2 INTERFACE

For simple connection and maximum bandwidth.

HIGH-DENSITY 3D TLC NAND

Provides the ideal mix of performance, endurance and value to keep your drive performing at its best for years.

COMPACT M.2 2280 FORM FACTOR

Ultra-compact M.2 2280 size fits directly into your notebook or motherboard with no additional cables or connectors.

COMPREHENSIVE FIVE-YEAR CORSAIR WARRANTY

Long-term reliability and industry leading customer support for peace of mind.

Tech Specs

Storage Form Factor	M.2 2280
Storage Temperature	-40°C to +85°C
Storage Humidity	93% RH (40° C)
SSD Package Contents	Force MP510 Series M.2 SSD
SSD Compatibility	m.2 2280 interface connector windows 10, mac os x
Form Factor	M.2 2280
Voltage	3.3V, +/- 5%
Vibration	20Hz~80Hz/1.52mm, 80Hz~2000Hz/20G
SSD Shock	1,500 G
SSD Operating Temperature	0°C to +65°C
NAND Technology	3D TLC

SSD Smart Support	Yes
SSD TBW	400
SSD Max Sequential Write CDM	Up to 1,050MB/s
SSD Max Sequential Read CDM	Up to 3,100MB/s
Max Random Read QD32 IOMeter	Up to 180K IOPS
Max Random Write QD32 IOMeter	Up to 240K IOPS
Capacity	240 GB
Interface	PCIE* 3 x 4
Weight	0.03kg
Memory Type	PCIe Gen 3.0 x4

Capacity: 1 GB is 1 Billion Bytes. Some of the listed capacity on a flash storage device is used for formatting and thus not available for data storage. The actual available capacity for data storage is less than the capacity stated on the products.
Performance: Performance rating based on internal testing at CORSAIR at the time of launch. Performance depends on the host platform, usage, and other variables.
Endurance: Endurance rating based on JEDEC JESD218 standard client workload. Individual drive endurance and health status depends on actual usage and may be less than rated endurance.
