All the storage you need
FITS UP TO
4X 2.5IN SSDS
2X 3.5IN HDDS
iCUE 5000D RGB Hydro X Edition Mid-Tower ATX PC Case
The CORSAIR 5000D RGB HX is a mid-tower ATX case with a pre-installed Hydro X Series XD7 RGB 360mm Pump/Reservoir Combo to start you on the way to a gorgeous distribution plate custom cooling system.
SKU: CC-9011228-WW
- Overview
- Tech Specs
- Compatibility
- Downloads
- Guides
- Package Contents
5000D RGB HYDRO X EDITION
MID-TOWER ATX CASE
CLEAR, CLEAN, AND COOL
MAXIMUM COOLING POTENTIAL
A spacious interior fits up to 7x 120mm fans along with multiple radiators including up to a 360mm on the side or roof.
CUSTOM COOLING IN LIVING COLOR
Every 5000D RGB HX features a Hydro X Series XD7 RGB 360mm distribution plate system with an integrated D5 PWM pump and 36 individually addressable LEDs to drive the world’s most demanding custom cooling systems and deliver eye-catching aesthetics.
Shown here in a finished build with XF Chrome fittings, XT Hardline tubing and XL5 Blue coolant (sold separately)
Extreme Cooling
Maximum Cooling Potential: A spacious interior fits up to 10x 120mm or 4x 140mm cooling fans, along with multiple radiators including up to a 360mm in front and a 360mm push/pull in the roof.
Expansion-friendly, the 5000D RGB HX has room for extensive air or liquid-cooled configurations
CORSAIR RAPIDROUTE CABLE MANAGEMENT
A spacious interior fits up to 7x 120mm fans along with multiple radiators including up to a 360mm on the side or roof.
1
2
3
4
5
MODERN FRONT PANEL I/O
Quickly and easily route your major cables through a single hidden channel, with a roomy 25mm of space behind the motherboard for all of your cables, easily concealed by a hinged steel door.
1
Power Button
2
2x USB 3.0 ports
3
USB 3.1 Type-C Port
4
Headphone/Mic Combo Jack
5
Reset Button
VERTICAL GPU MOUNT READY
With included vertical PCIe slots and a screw mount for a CORSAIR PCI-Express 3.0 extension cable (sold separately), you can show off your GPU and keep it secure at the same time.
UNITE YOUR SETUP
Tech Specs
| Case Supported | Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm) |
|---|---|
| Case Height | 520 |
| Case Length | 520 |
| Case Width | 245 |
| Lighting | RGB |
| Case Form Factor | MID TOWER |
| Motherboard Support | Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm) |
| Color | BLACK |
| Case Size | Mid-Tower |
| Radiator Compatibility | 120mm, 140mm, 240mm, 280mm, 360mm |
| Case Window | Tempered Glass |
| Case Dimensions | 520mm x 245mm x 520mm |
| Compatible Liquid Coolers | H55, H60, H75, H80i, H90, H100i, H105, H110i, H115i, H150i |
|---|---|
| Case Warranty | 2 Year |
| Internal 3.5" Drive Bays | 4 |
| Internal 2.5" Drive Bays | 2 |
| Maximum CPU Cooler Height | 170 |
| Maximum PSU Length | 250 |
| Case Front IO | (1x) USB 3.1 Type C, (2x) USB 3.0, (1x) Audio in/out |
| Maximum GPU Length | 420mm |
| Weight | kg |
| Case Expansion Slots | 7 vertical + 2 horizontal |
| Case Power Supply | ATX |
| Cable Routing Space | 43mm |
Hydro X Coolant Compatibility
| Coolant Brand | Coolant Model | Recommendation |
|---|---|---|
| CORSAIR | XL5 Performance Coolant | Preferred |
| CORSAIR | XL8 Performance Coolant | Preferred |
| Aquacomputer | Double Protect Ultra | Compatible |
| Coolaboratory | Liquid Coolant Pro | Compatible |
| EK | Cryofuel | Compatible |
| Jingway | Iceland X | Compatible |
| Koolance | LIQ-702 | Compatible |
| Liquid Cool | CFX Opaque | Compatible |
| Mayhems | IDC | Compatible |
| Mayhems | Pastel | Compatible |
| Mayhems | X1 | Compatible |
| Mayhems | XT-1 Nuke | Compatible |
| Mayhems | XT-1 | Compatible |
| Nanoxia | Cooling Fluid Pro | Compatible |
| Nanoxia | Cooling Fluid Pro Opaque | Compatible |
| Primochill | TRUE | Compatible |
| Thermaltake | C1000 | Compatible |
| XSPC | EC6 | Compatible |
| XSPC | ECX | Compatible |
| Alphacool | Eiswasser | Not compatible |
| Alphacool | Eiswasser Pastel | Not compatible |
| Alphacool | Cape Kelvin Catcher CKC | Not compatible |
| Aquatuning | AT-Protect | Not compatible |
| EK | Cryofuel Solid | Not compatible |
| EK | Cryofuel Mystic Fog | Not compatible |
| Jingway | Galaxy | Not compatible |
| Mayhems | SFX Aurora | Not compatible |
| Mayhems | XTR | Not compatible |
| Phobya | ZuperZero Xtreme | Not compatible |
| Primochill | Liquid Utopia | Not compatible |
| Primochill | VUE | Not compatible |
| Swiftech | HydrX | Not compatible |
| Thermaltake | C1000 Opaque | Not compatible |
| Thermaltake | Coolant 1000 | Not compatible |
| XSPC | EC6 Pastel | Not compatible |
| UFO Technologies | Cryo-Chillz | Not compatible |
| CORSAIR | |
|---|---|
| XL5 Performance Coolant | Preferred |
| XL8 Performance Coolant | Preferred |
| Aquacomputer | |
| Double Protect Ultra | Compatible |
| Coolaboratory | |
| Liquid Coolant Pro | Compatible |
| EK | |
| Cryofuel | Compatible |
| Jingway | |
| Iceland X | Compatible |
| Koolance | |
| LIQ-702 | Compatible |
| Liquid Cool | |
| CFX Opaque | Compatible |
| Mayhems | |
| IDC | Compatible |
| Pastel | Compatible |
| X1 | Compatible |
| XT-1 Nuke | Compatible |
| XT-1 | Compatible |
| Nanoxia | |
| Cooling Fluid Pro | Compatible |
| Cooling Fluid Pro Opaque | Compatible |
| Primochill | |
| TRUE | Compatible |
| Thermaltake | |
| C1000 | Compatible |
| XSPC | |
| EC6 | Compatible |
| ECX | Compatible |
| Alphacool | |
| Eiswasser | Not compatible |
| Eiswasser Pastel | Not compatible |
| Cape Kelvin Catcher CKC | Not compatible |
| Aquatuning | |
| AT-Protect | Not compatible |
| EK | |
| Cryofuel Solid | Not compatible |
| Cryofuel Mystic Fog | Not compatible |
| Jingway | |
| Galaxy | Not compatible |
| Mayhems | |
| SFX Aurora | Not compatible |
| XTR | Not compatible |
| Phobya | |
| ZuperZero Xtreme | Not compatible |
| Primochill | |
| Liquid Utopia | Not compatible |
| VUE | Not compatible |
| Swiftech | |
| HydrX | Not compatible |
| Thermaltake | |
| C1000 Opaque | Not compatible |
| Coolant 1000 | Not compatible |
| XSPC | |
| EC6 Pastel | Not compatible |
| UFO Technologies | |
| Cryo-Chillz | Not compatible |
iCUE 5000D RGB Hydro X Edition Mid-Tower Smart Case, Black
Accessory Kit
Quick Start Guide
