RM1000x SHIFT 80 PLUS Gold Fully Modular ATX Power Supply

CORSAIR RMx SHIFT Series fully modular power supplies boast a revolutionary patent-pending side cable interface to keep all your connections within easy reach, for exceptionally convenient 80 PLUS Gold efficient power.
$169.99USDCurrent price: $169.99$209.99Original price: $209.99Save -$40.00Discount: $40.00
This product qualifies for free shipping


  • Hardwareluxx
  • Hardware Busters
  • Kitguru
  • Cowcotland
  • ProfesionalReview
SKU: CP-9020253-NA

RMx SHIFT SERIES

RM1000x POWER SUPPLY

SIDE CONNECTOR INTERFACE FOR EASIER BUILDING

A PSU THAT'S ON YOUR SIDE
WATCH VIDEO

NO MORE FUMBLING AROUND

SIDE MOUNTED CONNECTIONS

An innovative patent-pending side PSU panel with modular connections lets you comfortably plug cables into the side face of the PSU, making it easier to connect and manage your cables than ever before.

Certification badges, a 12V-2x6 GPU cable, and a PC power supply unit.

ON THE CUTTING-EDGE

ATX 3.1 CERTIFIED

The ATX 3.1 standard demands a high level of reliability and power efficiency. While many CORSAIR PSUs meet these requirements, RMx SHIFT Series PSUs are formally certified for ATX 3.1 compliance.

PCIe 5.1 12V-2x6 GPU cables included for use with modern graphics cards such as the NVIDIA® GeForce RTX™ 40 Series.

FULLY MODULAR

CORSAIR TYPE 5 MICRO-FIT CONNECTORS

Fully modular, CORSAIR Type 5 Gen 1 micro-fit PSU cables, so you only connect the cables your system needs while taking up less space.

PC power supply with side connectors and installed cables.
PC power supply fan noise chart.

140mm FAN WITH ZERO RPM MODE SUPPORT

A low-friction, fluid dynamic bearing 140mm fan with Zero RPM mode support ensures your PSU runs cool while staying virtually silent when not under high load.

Low Noise Icon Zero RPM Mode Icon
Low Noise Icon Low Noise Icon Low Noise Icon

80 PLUS Gold certified

Steady power output at up to 90% efficiency, and Cybenetics-certified for lower power consumption, less noise, and cooler temperatures.

Low Noise Icon

105°C-RATED CAPACITORS

Built with 100% Industrial-grade, 105°C-rated Japanese electrolytic capacitors for unwavering power and reliability.

CASE COMPATIBILITY

The PSU and cables will fit in any PC case that supports ATX PSU format and is at least 210mm (8.3") wide. The PSU must also be accessible from the side when mounted in the case.

PC power supply with side connectors and installed cables.
CORSAIR 10-YEAR WARRANTY BADGE

TEN-YEAR WARRANTY

WORLD-CLASS SUPPORT

Our award-winning service means you can enjoy your gear worry-free.

RM1000x SHIFT POWER TABLE

MODEL RPS0161
Part No. CP-9020253/75-005192
AC Input Rating
AC Input 100–240V
Input Current 12A-6A
Frequency 47~63Hz
  Max Load Max Output
+3.3V 20A 150W
+5V 20A
+12V 83.3A 1000w
+5Vsb 3A 15W
Total Power 1000w

RM1000x SHIFT CABLE LISTING

QTY Cable Connectors
per cable
Total
connectors
Connector
spacing
Total
length
Cable Type
1

Modular ATX Cable (24-pin)

CORSAIR Modular ATX Cable (24-pin) cable illustration
1 1 - 610mm
(± 10mm)
Flat
2

EPS / ATX 12V 8-pin (4+4)

CORSAIR EPS / ATX 12V 8-pin (4+4) cable illustration
1 2 - 650mm
(± 10mm)
Flat
1

12V-2x6 (12+4) pin

CORSAIR 12V-2x6 (12+4) pin cable illustration
1 1 - 650mm
(± 10mm)
Flat
2

PCIe 8-pin (6+2) (6+2)

CORSAIR PCIe 8-pin (6+2) (6+2) cable illustration
2 4 600mm,
100mm
750mm
(± 10mm)
Flat
3

PCIe 8-pin (6+2)

CORSAIR PCIe 8-pin (6+2) cable illustration
1 3 - 650mm
(± 10mm)
Flat
4

SATA (4 SATA)

CORSAIR SATA (4 SATA) cable illustration
4 16 455mm,
115mm,
115mm,
115mm
800mm
(± 10mm)
Flat
2

PATA (4-pin)

CORSAIR PATA (4-pin) cable illustration
4 8 450mm,
100mm,
100mm,
100mm
750mm
(± 10mm)
Flat
